Description
Technical specifications
- Contacts: Double pole NONC contacts
- Contact Load: 0.5A @ AC 125V / 2A @ DC30V
- Voltage: 12/24 VDC @ 45mA operating
- +/- 10% voltage tolerance
- Legend: Touch Free Exit
- Button rated IP65 ingress protection
- Relay timer: 5 seconds
- Operating distance: 0-150mm
- -30° to +80° operating temperature
- Humidity: 20%-80%
- Designed to prevent interference with other infra red devices
- Requires a permanent power supply – volt free contacts
Features:
- 38mm / 22mm Touch free sensor button
- Illumination – Green to red (or red to green)
- Flush mounted box
- Can be surface fitting with EXTR03 or EXTR04
- Easy clean surface
- Ideal for general / sensitive areas
- Screw footprint for flush fitting onto standard back box
- Distance between fixing holes 60mm
