Description
Technical specifications
- Contacts : Double pole NONC contacts
- Contact Load: 0.5A @ AC 125V/2A @ DC30V
- Voltage: 12VDC @ 45mA operating
- +/- 10% voltage tolerance
- Legend: No Touch Exit
- Button rated IP65 ingress protection
- Relay timer: 5 seconds
- Operating distance: 0-150mm
Features:
- 35mm ‘Touch Free’ sensor button
- Illumination: Red for standby, Green for switch operated/door open
- Manufactured using anti-bacterial plastics
- High impact plastic back box
- Can be surface or flush fitting
- Easy clean surface
- Ideal for general/sensitive areas
- Screw footprint for flush fitting onto standard back box
- Distance between fixing holes: 60mm
